3/8" Supply port 3/8" Control port size 3/4" Reservoir port size 3/8" Delivery port size
Duty
N/A
Flow C
N/A
Flow Rating
Nominal crack pressure of 4.5 PSI
Function
Do not use this valve on converter dollies, trailer turntable axles or lift axles due to the hard braking ratio feature.
Operating Temperature Range
N/A
Operation
Regulates are flow to air brakes on trailers with regular drive axles; do not use on dollies; steerable drops, or regular drop axles due to the hard braking ratio.
