POWER BEYOND SLEEVE
Call to Order
Backordered and on the way. Will ship when in stock
SKU# H-8006
The power beyond sleeve prevents subjecting the exhaust or return passages and spool seals of the control valve to back pressure.
Power Beyond Sleeve: The power beyond sleeve prevents subjecting the exhaust or return passages and spool seals of the control valve to back pressure. Note: since the return passage is blocked from normal outlet, it is necessary to provide an additional outlet which is to be hooked up to tank or reservoir.
Maximum Flow Rate 30 gallons per minute
3/4" port
Keeps control valve from experiencing back pressure
Commonly used on the hydraulic systems with hydraulic powered dump beds
Maximum Flow Rate 30 gallons per minute
3/4" port
Keeps control valve from experiencing back pressure
Commonly used on the hydraulic systems with hydraulic powered dump beds
| Box Size | 8"x6"x6" |
|---|---|
| Country of Origin | USA |
| Function | The power beyond sleeve prevents subjecting the exhaust or return passages and spool seals of the control valve to back pressure. |
| Electrically Operated | NO |
| Inlet Port Size | 3/4" |
| Main Relief Setting | 30 GPM |
| Maximum Flow Rate | Maximum Flow Rate 30 gallons per minute |
| Maximum Pressure | 1500 PSI |
| Outlet Port Size | 3/4" |
| Power Beyond | YES |
| Spool Action | YES |
| Work Port Size | 3/4" |
