AIR BAG (1R12-069)

Call to Order
SKU# FS9069
AIR BAG (1R12-069)
Goodyear Air Bag: Air bags are used on trailers and trucks for the suspension system. The trucks air system supplies all the needed air for the bags to function properly. Most common bags are ride bags, steer axle ride bags, and drop axle lift bags. Function with the help of the air compressor on the truck, leveling valves, and pressure protection valves.
Top Plate Hole/Stud: 3
Bottom Plate Hole/Stud: 1
Top Plate Diameter: 9"
Bottom Plate Diameter: 9.8"
Collapsed Height: 7.5"
More Information
Length 19
Width 11
Height 19
